Description
laser Marking Printer F20
|
Model |
F20/30/50 |
|
|
Output Power |
20w/30w/50w100w optional |
|
|
Laser wavelength |
1064nm/10.64um/355nm |
|
|
Laser |
fiber/UV laser type optional |
|
|
Print height |
1m-100mm |
|
|
Print lines |
Unlimited rows |
|
|
Print font |
Online editing, QR code, barcode, garbled characters (4-20 digits), upper and lower case English letters, Arabic numerals and commonly used symbols, automatic date, Chinese characters and trademark patterns can be edited directly |
|
|
Enter information |
10 inch full color touch screen |
|
|
Operating system |
CLLASER independent research and development |
|
|
Pipeline length |
Standard 1.5 meters (optional) |
|
|
Protection class |
Ip54, laser forced air cooling |
|
|
Marking format |
70 × 70mm, 110 × 110mm, 145 × 145mm, 175 × 175mm (optional) |
The speed depends on the length, size, complexity and marking material of the printed information |
|
Scribing speed |
120-145m / min |
|
|
Power supply |
500WAC 220V 50HZ |
|
|
Total measurement |
Main box: 530×198×360, optical path: 540×98×125 |
|
|
Adjust space |
1D, 2D, 3D (optional) |
|
